品 番
stock number |
HOTmeltG |
特 性
characterristic |
■ 加熱すると融解して強力な接着材となる。
①強力接着剤
ナイロン、布織物（但し､ﾗｲｸﾗ、ｽﾊﾟﾝﾃﾞｯｸｽを除く）、皮革、シューズ、木材
塩化ﾋﾞﾆｰﾙ、ABS、PET、ｱﾙミ箔、アルミニウム、アルミホイルマイラー
発泡ｽﾃｨﾛｰﾙ、刺繍パッチ、かつらなどに有効
②接着力は季節に関係なく、ﾄﾞﾗｲｸﾘｰﾆﾝｸﾞや選択にも強い。 |
材 質
material |
ポリエステル
PES |
化学成分
chmical composition |
ポリエステル加熱融解/接着フィルム
PES hot melt adhesive glue film |
物理的形状
pysical form |
剥離用紙つきの膜状固体
solid membranous with release paper |
色
colors |
乳白(半透明）
translucent milk-white |
融解点
melting point（℃） |
105℃ |
合成樹脂の流動性測定
melt index(g/10min) |
25g/10min
melt index(g/10min)
加熱された円筒容器内で一定量の合成樹脂を、定められた温度で加熱・加圧し、
容器底部に設けられた開口部（ノズル）から10分間あたりに押出された樹脂量を測定する。
値は単位：g/10minで表示される。
|
厚さ
thickness(mm） |
0.08mm（80ミクロン） |
幅
width（ｃｍ） |
50ｾﾝﾁ
width（ｃｍ） |
長さ
length(yard) |
100ﾔｰﾄﾞ（約９１ﾒｰﾄﾙ）
length(yard) |
加熱ﾌﾟﾚｽ温度
hot press temperature(℃） |
120～160℃ |
|
|
（参考事項①）
Product Introduction
Hot melt adhesive film, known as hot melt glue, hot melt back adhesive,
is composed of hot melt adhesive film layer and release paper.
At normal temperature,it is similar to ordinary film, after heating, producing
stickiness
Its heating and pressing process is simple, and has high peel strength,
wash&dry cleaning resistance, i
It’s environmentally friendly and non-toxic.
Product Features：
1.Rapid adhesion, wide bonding range, easy to operate.
2.Uniform weight distribution on film surface, fully adhesive.
3. Single layer or multilayer lamination.
4.With good elasticity, tensile force, folding strength, and wash resistance.
Technical Data：
|
Product Code
|
ZPMS-film001
|
ZPMS-film002
|
ZPMS-film003
|
ZPMS-film004
|
ZPMS-film005
|
|
Delivery form
|
Film
|
Film
|
Film
|
Film
|
Film
|
|
Weight range（g/m2)
|
0.02-0.2
|
0.02-0.2
|
0.02-0.2
|
0.02-0.2
|
0.02-0.2
|
|
Width(mm)
|
5-1600
|
5-1600
|
5-1600
|
5-1600
|
5-1600
|
|
Mp(℃)
|
60
|
85
|
115-120
|
120-130
|
150-160
|
|
Bond strength(N/5C㎡)
|
＞10
|
＞10
|
＞10
|
＞10
|
＞10
|
|
Washable(40℃)
|
**
|
***
|
***
|
***
|
***
|
|
Washable(60℃)
|
*
|
**
|
**
|
**
|
***
|
|
Resistance to dry cleaning(℃)
|
*
|
**
|
**
|
**
|
***
|
|
Pressing temperature(℃)
|
80-90
|
110-115
|
135-1150
|
150-160
|
170-180
|
|
Pressing time(S)
|
15-20
|
15-20
|
15-20
|
15-20
|
15-20
|
|
Pressure(kgf/C㎡)
|
0.3-0.5
|
0.3-0.5
|
0.3-0.5
|
0.3-0.5
|
0.3-0.5
|
|
Applicable
|
For a variety of textile fabrics, PVC, ABS, PET, metal fiber, plastic, oily leather and various leather, mesh, aluminum foil, aluminum, wood, reflective heat foil, aluminum foil Mylar, TPR, conductive fabric, poly ester foam polyether foam, PU foam, flocking transfer, etc.; main application areas: clothing, accessories, shoes standard, seamless shoe materials, reflective materials, electronic shielding EMI and other
|
|
Note: Pressing the conditions for reference only, and the pressure of hot equipment, material thickness to be fit, the pressure was the relationship between user needs are recognized according to the specific experimental conditions
|
|
|
|
（参考事項②）
ご参考まで：注）難しくてうまく訳せません。
Hot melt adhesive glue film
Our product is a kind of a latest environmental protection product.
It is of high bond intensity;has no resistance
to laundering and dry cleaning.
It is widely applied to bond many kinds of non-laundering fabrics; leather; non-woven fabrics; wooden materials; paper; plastic
and other materials, good bond effect in laser paper.
Application: It is used for the adhensive of embroidery logo,melt decal,electronic,IT,auto fabric bonding,metal
alumium building materials
Specification
1. Thickness: 0.08mm, etc
2. Size: 50cmx100 yards, etc.
3. Appearance: milky white(semi=transparent)
4. Material: polymer improved materials
5. Melting point: 90℃
6. Temperature: 130-180℃
7. Pressure:0.5-1.5kg/cm²
8. Time: 5-20s
Product Details
Hot melt adhesive glue film
The hot-melt adhesives have a number of important properties, making them suitable for different applications:
この加熱融解,接着フィルムは多くの長所があり、利用方法は多岐二わたる。
§ Open time,
the working time to make a bond, where the surface still retains sufficient tack,
can range fromseconds for fast-setting HMAs to infinity for pressure-sensitive adhesives
§ Set time,
time to form a bond of acceptable strength
§ Bond-formation temperature,
minimum temperature below which sufficient wetting of substrates do not occur
§ Melt viscosity,
one of the most important properties. Influences the spread of applied adhesive,
and the wetting of the surfaces. Temperature-dependent, higher temperature lowers viscosity.
§ Melt flow index,
a value inversely proportional to the molecular weight of the base polymer.
High melt flow index adhesives are easy to apply but have poor mechanical properties due to short polymer chains.
Low melt flow index adhesives have better properties but are more difficult to apply.
§ Surface energy,
which influences wetting of different kinds of surfaces.
§ Pot life stability,
the degree of stability in molten state, the tendency to decompose and char.
Important for industrial processing where the adhesives are molten for prolonged periods before deposition.
|
|
